鋁合金高空作業平臺
鋁合金高空作業平臺
產品類型：鋁合金高空作業平臺
產品型號：單桅,、雙桅,、三桅,、四桅、六桅,，可達23米
產品顏色：按需調配
生產周期：10-15天（具體按產品的配置程度和生產線繁忙程度調整）
產品用途：載人進行高空作業維修,、保養,、清潔,、裝修等
服務特色：工廠直銷、一年質保,、終身平價維護
產品運輸：汽運,，全國送貨上門
注：產品為標準品，可接受定制,。
| 序號 | 產品名稱 | 型號-代號 | 平臺最大高度m | 平臺最大作業高度m | 額定載荷KG | 平臺尺寸m | 電源電壓V /HZ | 功率KW | 質量KG | 外形尺寸m |
| 1 | 單桅 | GTWY4-100 | 4 | 5.7 | 125-150 | 0.64*0.58 | AC220/50HZ | AC220/0.75 | 250 | 1.18*0.80*1.65 |
| 2 | 單桅 | GTWY6-100 | 6 | 7.7 | 125-150 | 0.64*0.58 | AC220/50HZ | AC220/0.75 | 280 | 1.28*0.80*1.65 |
| 3 | 單桅 | GTWY8-100 | 8 | 9.7 | 125-150 | 0.64*0.58 | AC220/50HZ | AC220/0.75 | 300 | 1.28*0.80*1.98 |
| 4 | 單桅 | GTWY9-100 | 9 | 10.7 | 125 | 0.64*0.58 | AC220/50HZ | AC220/0.75 | 320 | 1.28*1.85*1.98 |
| 5 | 雙桅 | GTWY6-200S | 6 | 7.7 | 200-300 | 1.10*0.60 | AC220/50HZ | AC220/1.1 | 420 | 1.28*0.80*1.65 |
| 6 | 雙桅 | GTWY7-200S | 7 | 8.7 | 200-300 | 1.16*0.60 | AC220/50HZ | AC220/1.1 | 450 | 1.36*0.85*1.98 |
| 7 | 雙桅 | GTWY8-200S | 8 | 9.7 | 200-300 | 1.16*0.60 | AC220/50HZ | AC220/1.1 | 480 | 1.36*0.85*1.98 |
| 8 | 雙桅 | GTWY9-200S | 9 | 10.7 | 200-300 | 1.32*0.60 | AC220/50HZ | AC220/1.1 | 500 | 1.50*0.90*1.98 |
| 9 | 雙桅 | GTWY10-200S | 10 | 11.7 | 200-300 | 1.32*0.60 | AC220/50HZ | AC220/1.1 | 530 | 1.50*0.90*2.04 |
| 10 | 雙桅 | GTWY11-200S | 11 | 12.7 | 200 | 1.32*0.60 | AC220/50HZ | AC220/1.1 | 550 | 1.56*0.90*2.04 |
| 11 | 雙桅 | GTWY12-200S | 12 | 13.7 | 200 | 1.42*0.60 | AC220/50HZ | AC220/1.1 | 580 | 1.66*0.97*1.98 |
| 12 | 雙桅 | GTWY14-200S | 14 | 15.7 | 200 | 1.42*0.60 | AC220/50HZ | AC220/1.1 | 600 | 1.66*1.10*2.38 |
| 13 | 叁桅 | GTWY13-320 | 13 | 14.7 | 200-250 | 1.56*0.80 | AC220/50HZ | AC220/2.2 | 800 | 1.69*1.25*2.28 |
| 14 | 叁桅 | GTWY14-320 | 14 | 15.7 | 200-250 | 1.56*0.85 | AC220/50HZ | AC220/2.2 | 900 | 2.00*1.25*2.45 |
| 15 | 叁桅 | GTWY15-320 | 15 | 16.7 | 200-250 | 1.56*0.85 | AC220/50HZ | AC220/2.2 | 1000 | 2.20*1.25*2.45 |
| 16 | 四桅 | GTWY14-420 | 14 | 15.7 | 200-250 | 1.56*0.85 | AC220/50HZ | AC220/2.2 | 12000 | 2.00*1.25*2.45 |
| 17 | 四桅 | GTWY16-420 | 16 | 17.7 | 200-250 | 1.60*0.85 | AC220/50HZ | AC220/2.2 | 1400 | 2.20*1.25*2.45 |
| 18 | 六桅 | GTWY18-620 | 18 | 19.7 | 150 | 1.36*0.90 | AC220/50HZ | AC220/2.2/1.1 | 1700 | 2.30*1.30*2.45 |
| 19 | 六桅 | GTWY20-620 | 20 | 21.7 | 150 | 1.36*0.90 | AC220/50HZ | AC220/2.2/1.1 | 1800 | 2.45*1.30*2.45 |
| 20 | 六桅 | GTWY22-620 | 22 | 23.7 | 150 | 1.36*0.90 | AC220/50HZ | AC220/2.2/1.1 | 1900 | 2.45*1.50*2.70 |
| 21 | 六桅 | GTWY24-620 | 24 | 25.7 | 150 | 1.36*0.90 | AC220/50HZ | AC220/2.2/1.1 | 2000 | 2.45*1.60*2.80 |
